Plant for Tack Welds on the Tank Shell

Plant for Tack Welds on the Tank Shell

It designed to finish the longitudinal seam of the shell when the vessel of the oil tank car is produced.

Specifications

Dimensions of the workpiece to be assembled, mm

Ø, mm

3 220

Length, mm

9 450

Weight, kg

7 400

Air pressure in hydraulic system, MPa

0,4.0,5

Pressed air consumption, m³/h

0,5

Adjusted power, Kw

8,4

Dimensions, mm

11795х4280х3920

Weight, kg

10300
