Lifting jack for main frame aligning
The lifting jack has been designed for locomotive main frame aligning operations.
Specifications:
|
1. |
Lifting jack load capacity, t |
120 |
|
2. |
Nominal load capacity of one jack, t |
30 |
|
3. |
Jacks qt. |
4 |
|
4. |
Lifting height, mm |
1100…1400 |
|
5. |
Lifting speed, cm/min |
20,4 |
|
6. |
Lifting jack electriс drive capacity, kW |
5,5 |
|
7. |
Frequency,Hz |
50 |
|
8. |
Voltage in the mains, V |
380 |
|
9. |
Nominal load capacity of the column, t |
40 |
|
10. |
Columns qt. |
12 |
|
11. |
Column rotation angle, degrees |
35 |
|
12. |
Air pressure in pneumatic system, MPa |
0,6…0,8 |
|
13. |
Air consumption m³⁄ h |
2,5 |
|
14. |
Installed capacity, kW |
22,1 |
